Victron Energy Centaur 12VDC 80Amp 3-Bank Battery Charger (Part CCH012080000)

Centaur Charger - 12 VDC - 80AMP - 3-Bank - 120-240 VAC

Features:

• Quality without compromise - Aluminium epoxy powder coated cases with drip shield and stainless steel fixings withstand the rigors of an adverse environment: heat, humidity and salt air. Circuit boards are protected with an acrylic coating for maximum corrosion resistance. Temperature sensors ensure that power components will always operate within specified limits, if needed by automatic reduction of output current under extreme environmental conditions.
• Universal 90-265V AC input voltage range and also suitable for DC supply (AC-DC and DC-DC operation) All models will operate without any adjustment needed over a 90 to 265 Volt input voltage range, whether 50 Hz or 60 Hz.
• The chargers also accept a 90-400 V DC supply.
• Three outputs that each can supply the full output current Three isolated outputs to simultaneously charge 3 battery banks Each output is capable to supply the full rated current.
• Three-stage charging, with temperature compensation The Centaur charges at bulk rate until the output has reduced to 70% of the rated Amps, at which a 4 hour timer begins. After the timed period the charger switches to float rate. An internal temperature sensor is used to compensate the charge voltage with 2 mV/C ( 1 mV/F) per cell. A DIP switch is available to select the optimum charge/float voltages for Flooded Lead-acid, Gel or AGM batteries

Warranty Info

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Victron Energy Centaur charger model CCH012080000 is a versatile and durable solution designed for demanding environments. Crafted with an aluminium epoxy powder-coated case, this charger features a drip shield and stainless steel fixings that resist heat, humidity, and salt air, ensuring reliable operation in harsh conditions. Its acrylic-coated circuit boards further enhance corrosion resistance, while integrated temperature sensors allow for automatic current reduction under extreme environmental conditions, safeguarding your batteries and equipment.
The Centaur charger supports a wide input voltage range from 90 to 265 volts AC, making it suitable for global applications without requiring adjustments. It also accepts a DC supply of 90 to 400 volts, providing flexibility for various power sources. The three isolated outputs enable simultaneous charging of three separate battery banks at their full rated current, streamlining multi-bank charging setups. Each output is capable of delivering up to 80 amps, ensuring rapid and efficient charging.
This charger employs a three-stage charging process with temperature compensation to optimize battery health and longevity. It charges at a bulk rate until the battery reaches 70% of its capacity, then switches to float mode after a four-hour timer. An internal temperature sensor adjusts the charge voltage by 2 mV per degree Celsius per cell, depending on the battery type—Flooded Lead-Acid, Gel, or AGM. A DIP switch allows users to select the most appropriate voltages for different battery chemistries, ensuring compatibility and maximum performance.
For detailed instructions and warranty information, refer to the owner’s manual available online. Please note that this product contains chemicals known to the State of California to cause cancer and reproductive harm, as noted in the P65Warnings. For support, repairs, or returns, contact your dealer. The Victron Centaur charger is an essential component for reliable battery management in diverse environments, combining high-quality construction with advanced charging features.

Features:

• Durable aluminium epoxy powder-coated case with drip shield and stainless steel fixings for harsh environments

• Acrylic-coated circuit boards for maximum corrosion resistance

• Integrated temperature sensors for automatic current reduction in extreme conditions

• Universal input voltage range from 90 to 265 volts AC and accepts 90 to 400 volts DC

• Three isolated outputs capable of supplying full rated current simultaneously

• Three-stage charging with temperature compensation for battery longevity

• Selectable charge and float voltages for different battery chemistries (Flooded Lead-Acid, Gel, AGM)
