Victron Energy Phoenix Smart IP43 Charger 24/16 (1+1) 120-240VAC - Adaptive Battery Charging with Bluetooth Monitoring

Phoenix Smart IP43 Charger 24/16 (1+1) 120-240VAC Requires 5-15P Mains Cord (cord not included)

With boat owners in mind, this adaptive 5-step charger can provide either 30A or 50A of charge to each of the three battery banks. Or the Phoenix 1+1 model provides 3A to the starter battery, the rest to the house bank. 24V models are available with a 16A/25A charge. Bluetooth enabled, you can monitor the charger and set alarms straight from your phone.

Features:

• Bluetooth Smart built-in: The wireless solution to set up, monitor, update and synchronize Phoenix Smart IP43 Chargers.
• Phoenix Smart (1+1): two outputs to charge 2 battery banks: The second output, limited to approximately 4A and with a slightly lower output voltage, is intended to top up a starter battery.
• Phoenix Smart (3): three full current outputs to charge 3 battery banks: Each output can supply the full rated output current. But the total of the 3 outputs combined can never exceed the current rating of the charger.
• Automatic voltage compensation: The charger compensates for voltage drop over the DC cabling by slightly increasing output voltage when the DC current increases.
• Adaptive 6-stage charge algorithm: bulk absorption recondition float storage refresh: The Phoenix Smart Charger features our well-known adaptive battery management system that can be preset to suit different types of batteries. The adaptive feature will automatically optimize the charging process relative to the way the battery is being used.
• The right amount of charge: variable absorption time: When only shallow discharges occur (a yacht connected to shore power for example) the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge, the absorption time is automatically increased to make sure that the battery will be fully charged.
• Preventing damage due to excessive gassing: the BatterySafe mode: If in order to quickly charge a battery, a high charge current in combination with a high absorption voltage has been chosen, the charger will prevent damage due to excessive gassing by automatically limiting the rate of voltage increase once the gassing voltage has been reached.
• Less maintenance and aging when the battery is not in use: the Storage Mode: The Storage Mode kicks in whenever the battery has not been subjected to discharge for 24 hours. In the Storage Mode, float voltage is reduced to 2,2 V/cell (13,2 V for a 12 V battery) to minimize gassing and corrosion of the positive plates. Once a week the voltage is raised back to the absorption level to equalize the battery. This feature prevents stratification of the electrolyte and sulphation, a major cause of early battery failure.
• Also charges Li-ion (LiFePO4) batteries: Charger on-off control can be implemented by connecting a relay or open collector optocoupler output from a Li-ion BMS to the remote on-off port. Alternatively, full control of voltage and current can be achieved with Bluetooth.
• Fully programmable charge algorithm: The charge algorithm can be programmed with help of Bluetooth or the VE.Direct interface. Three preprogrammed algorithms can be selected with the mode button.
• Optional external battery voltage and temperature sensing via Bluetooth: A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more Phoenix Smart IP43 Chargers.
• Remote on-off: The remote on/off consists of two terminals: Remote H and Remote L. A remote on/off switch or relay contact can be connected between H and L. Alternatively, terminal H can be pulled high, or terminal L can be pulled low.
• VE.Direct interface: For a wired data connection to a Color Control panel, PC, or other devices.
• Programmable relay: Can be programmed using the VE.Direct interface or a Bluetooth-enabled device to trip on an alarm or other events.
• Synchronized charging: Pairing two or more Phoenix Smart IP43 Chargers in a VE.Smart Network, enables synchronized charging. This improves the charge efficiency and battery life.

The Victron Energy Phoenix Smart IP43 Charger 24/16 (Part Number: PSC241651095) offers advanced, adaptive charging solutions suitable for a variety of battery banks, making it ideal for boat owners and RV enthusiasts. Designed to deliver flexible power options, this charger can provide either 30A or 50A to each of three battery banks or 3A to a starter battery while supporting multiple configurations. Its ability to operate on 120-240VAC mains power and compatibility with a 5-15P cord (not included) ensures versatile installation options. Built-in Bluetooth Smart technology allows users to effortlessly monitor and configure the charger remotely via smartphone, providing real-time status updates and alarm settings for enhanced convenience and security.

Features:

• Bluetooth Smart built-in: Enables wireless setup, monitoring, updates, and synchronization via a smartphone app for user-friendly control.

• Phoenix Smart (1+1): Dual outputs to charge two battery banks with a dedicated 3A output for the starter battery, ensuring efficient maintenance of multiple power sources.

• Phoenix Smart (3): Three full current outputs to independently charge three battery banks, with the total current limited to the charger’s rated capacity for safe operation.

• Automatic voltage compensation: Adjusts output voltage dynamically to account for voltage drops over cabling, optimizing charging efficiency.

• Adaptive 6-stage charge algorithm: Incorporates bulk, absorption, recondition, float, storage, and refresh stages, automatically tailoring the process to different battery types and usage patterns.

• Variable absorption time: Automatically adjusts absorption duration based on discharge level, preventing overcharging during shallow discharges or ensuring full charge after deep discharges.

• BatterySafe mode: Limits voltage increase during rapid charging to prevent excessive gassing and damage, prolonging battery lifespan.

• Storage Mode: Reduces float voltage after 24 hours of inactivity to minimize electrolyte gassing and corrosion, with weekly reconditioning to prevent stratification and sulphation.

• Li-ion (LiFePO4) compatibility: Supports charging of lithium batteries with remote control options via Bluetooth or relay connections.

• Fully programmable charge profiles: Customize charging algorithms through Bluetooth or VE.Direct interface, with three preset modes for different battery types.

• Optional external sensing: Supports Bluetooth-connected voltage and temperature sensors like Smart Battery Sense or BMV-712 for precise monitoring.

• Remote on-off control: Connect external switches or relays to manage charging remotely for added flexibility.

• VE.Direct interface: Provides wired data communication with control panels, PCs, or other compatible devices.

• Programmable relay: Set alarms or trigger events through Bluetooth or VE.Direct programming.

• Synchronized charging: Pair with additional Phoenix Smart IP43 Chargers via VE.Smart Network for coordinated, efficient charging across multiple units.
