Victron Energy Skylla 24/100 TG Battery Charger - 230V, 500-1000 Ah Capacity

Skylla - 24/100 TG Charger - 230V

One full rated output and one (1) 4 Amp output. Charge voltage can be precisely adjusted to suit any battery system.

The input for the charger is 230V at 50/60HZ. Charge voltage can be measured directly on the battery terminals in order to compensate for voltage loss due to cable resistance.

An external sensor allows to measure battery temperature and compensate charge voltage accordingly.

Features:

• Perfect chargers for any type of battery - Charge voltage can be precisely adjusted to suit any sealed or unsealed battery system. In particular, sealed maintenance-free batteries must be charged correctly in order to ensure long service life. Overvoltage will result in excessive gassing and venting of a sealed battery. The battery will dry out and fail.
• Suitable for AC and DC supply (AC-DC and DC-DC operation)
• Every TG Charger has a microprocessor, which accurately controls the charging in three steps
• Use of TG Chargers as power supply - As a result of the perfectly stabilized output voltage, a TG Charger can be used as a power supply if batteries or large buffer capacitors are not available.
• Manufactured with a battery temperature sensor. When connected, charge voltage will automatically decrease with increasing battery temperature.
• In order to compensate for voltage loss due to cable resistance, TG Chargers are provided with a voltage sensor so that the battery always receives the correct charge voltage

Technical Specifications:

• Input Voltage - 230V AC
• Input Voltage Range - 185 to 264V AC
• Input Voltage Range - 180 to 400V DC
• Battery Capacity - 500 to 1000 Ah
• Frequency - 45 to 65 Hz
• Battery Connection - M8 studs
• 230V AC Connection - Screw clamp (AWG 6)
• Dimensions (H x W x D) - 14.4" x 9.9" 10.1" (36.5 x 25 x 25.7 cm)
• Weight - 22 Lbs (10 kg)

In the Box:

• Charger
• Mounting brackets
• Temperature sensor with 4.9' (1.5 M) wire
• Instruction manual

*Sold as an Individual

The Victron Energy Skylla 24/100 TG Charger is a versatile and reliable power solution designed for demanding battery systems. With a full rated output and an additional 4 Amp output, this charger offers precise control over charging parameters, making it suitable for a wide range of sealed and unsealed batteries. Its adjustable charge voltage ensures optimal charging, which is critical for maintaining battery health and longevity, especially for maintenance-free sealed batteries that require specific voltage regulation to prevent overgas and drying out.

The charger operates on a 230V AC input at 50/60Hz, with the ability to directly measure voltage at the battery terminals to compensate for voltage drops caused by cable resistance. An integrated external temperature sensor automatically adjusts the charge voltage based on battery temperature, further safeguarding battery performance and extending service life. This feature is especially beneficial in environments with fluctuating temperatures, as it helps prevent overcharging or undercharging of batteries.

Designed with advanced microprocessor control, the Skylla 24/100 TG employs a three-step charging process that ensures efficient and safe battery charging. It can also function as a power supply due to its highly stabilized output voltage, making it suitable for applications where a consistent power source is needed without batteries or large buffer capacitors. The device’s robust construction includes M8 studs for battery connections and screw clamp terminals for 230V AC input, facilitating secure and reliable connections. Its compact dimensions and lightweight design make installation straightforward, and it is supplied with mounting brackets, a temperature sensor with a 4.9-foot wire, and an instruction manual for ease of setup.

Engineered for durability and precision, the Victron Skylla 24/100 TG Charger is ideal for large battery banks with capacities ranging from 500 to 1000 Ah. Whether used in renewable energy systems, marine applications, or backup power setups, this charger ensures optimal battery performance and longevity. For support, repairs, or returns, please contact your dealer. The included manual provides detailed guidance on installation and operation, ensuring you maximize the benefits of this advanced charging solution.

Features:

• Adjustable charge voltage for compatibility with various battery types

• Suitable for AC and DC supply (AC-DC and DC-DC operation)

• Microprocessor-controlled with three-step charging process

• Can be used as a power supply due to stabilized output voltage

• Integrated battery temperature sensor for automatic voltage compensation

• Voltage measurement at battery terminals to offset cable resistance

• Heavy-duty connections with M8 studs and screw clamp terminals

• Compact design with easy installation options

• Designed for large battery banks (500 to 1000 Ah capacity)
