Victron Energy SmartSolar MPPT 150/60-TR Solar Charge Controller with Bluetooth Connectivity

SmartSolar MPPT 150/60-TR

The Victron SmartSolar MPPT 150/60 Solar Charge Controller is Bluetooth accessible via either built-in Bluetooth or the Victron Energy Bluetooth dongle. The VictronConnect app is available for free on both iOS and Android. This app allows you to view plenty of parameters: battery voltage, solar history, load output, flexible battery charge algorithms, plus day/night timing and light dimming options. These solar charge controllers will gather energy from your solar panels fast and efficiently.

Ultra-fast Maximum Power Point Tracking (MPPT) Especially in the case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers. Load output Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage. Alternatively, an intelligent battery management algorithm can be chosen: see Battery Life.

The load output is short circuit proof. Some loads (especially inverters) can best be connected directly to the battery, and the inverter remote control is connected to the load output. A special interface cable may be needed, please see the manual Battery Life: intelligent battery management When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a partially charged state and the end of discharge state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months.

MPPT: Ultra Fast Maximum Power Point Tracking

By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.

The Victron Energy SmartSolar MPPT 150/60-TR is a high-performance solar charge controller designed to maximize energy harvest from your solar panels. Equipped with ultra-fast Maximum Power Point Tracking (MPPT) technology, it ensures up to 30% more efficiency in energy collection compared to traditional PWM controllers and up to 10% more than slower MPPT models. This efficiency gain is especially noticeable under partly cloudy conditions, where changing light levels can reduce the effectiveness of less responsive controllers. The unit is Bluetooth-enabled via built-in Bluetooth or with a Victron Bluetooth dongle, allowing remote monitoring and configuration through the free VictronConnect app available on both iOS and Android devices. This integration provides comprehensive access to parameters such as battery voltage, solar generation history, load output status, and customizable battery charging algorithms, including day/night timing and light dimming options. The controller's compact design and intelligent features make it suitable for various solar power applications, from small off-grid systems to larger installations. The load output is short circuit proof and designed to prevent battery over-discharge by disconnecting loads at pre-set voltages or via an intelligent battery management algorithm that prolongs battery life. Connecting loads directly to the load output allows for safe operation of inverters and other devices, with compatibility for remote control through interface cables. The Victron SmartSolar MPPT 150/60-TR is built to optimize energy harvesting, extend battery lifespan, and simplify system management, making it a reliable choice for sustainable power solutions. Please consult the owner’s manual for detailed installation and operation instructions, available online through the provided link.

Features:

• Ultra-fast MPPT technology for maximum energy harvest, especially under fluctuating sunlight conditions

• Bluetooth connectivity via built-in module or Victron Bluetooth dongle for remote system monitoring using the VictronConnect app

• Battery management: prevents over-discharge with pre-set voltage disconnect or intelligent algorithms

• Load output: short circuit proof, designed to safely control loads and protect connected batteries

• Flexible configuration options including day/night timing and light dimming for optimized system performance
