Xantrex Freedom XC PRO 2000 2000W Marine Inverter Charger 12vDC in 120vAC Out

Overview of Xantrex Freedom XC PRO 2000 Marine Inverter Charger

Xantrex Freedom XC PRO 2000 2000W Marine Inverter Charger 12vDC in 120vAC Out

Xantrex Freedom XC PRO Marine 2000

Model: 818-2015

• Extended Surge Rating: Surges to 2X continuous power for 5 seconds for motor loads
• True Sine Wave AC Power: For operation of sensitive and motor loads
• Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off
• Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis
• Programmable AC Under-Voltage (85-110VAC) Shutdown: Feature ideal to operate under weak shore power or generator input
• Easily configurable settings to charge any lithium ion battery
• Power Factor Corrected Multi-Stage Charging: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances and reduces the likelihood of tripping shorepower breakers
• Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V
• Battery Equalization: Maximizes flooded battery life
• Dead Battery Charging Down to 0 Vdc
• Power Share: Prioritizes AC loads by reducing the charge current and maintaining the total input current to less than the breaker setting

A true sine wave inverter with a built-in lithium-ion battery charger and transfer switch in a compact, lightweight footprint. Configure and monitor system performance via Bluetooth app available on the optional Bluetooth remote panel (# 808-0817-02). SEAMLESS INTEGRATION WITH MICRO-C NMEA 2000 CONNECTOR

The Freedom XC PRO Marine inverter/charger, supporting CANbus NMEA 2000 protocol, is the most versatile and flexi- ble AC power solution in the market today. It supports seamless integration with third party monitoring and control systems. It also features a 100 amp (2000W model) / 150 amp (3000W model) battery charger and offers all of the configurable features of the Freedom XC series inverter/charger in a compact, light weight package. It cranks out full output in invert or charge mode from -4 degF (-20 degC) - 104 degF (40 degC) for operation in all climate temperatures. The extended surge rating enables compressor loads such as an A/C or a fridge to start reliably.

Specifications

AC Output Operating Voltage Options120, 110, 108 Vac

Continuous Output Power
Continuous Power 2000 W @40oC True sine wave
(TSW)

Continuous AC Output Current
16.7 A

Surge Power
4000 W ( 5 sec)

Frequency (Configurable)
60 (or 50) Hz

Peak Efficiency
91%

Full Load Efficiency
gretaer than or equal to 86%

DC Input Operating voltage range
10.1 - 18.0 VDC

DC Input Max Non-Operating Voltage
25.2 Vdc

DC Nominal Current at Full Load
192 Adc

ELECTRICAL SPECS - BATTERY CHARGER

Min Battery Voltage for Charging
0.0 Vdc

Max DC Output Voltage
18.0 Vdc (custom battery type)

Selectable DC Output Current
User Selectable: 5 - 100 A

Full Load Max AC Input Current
24 Arms

Max DC Charge Current (selectable down to 5A)
100A

Operating Input AC Pass-Through Voltage Range
85-140 Vac

Safe Non-Operating Input AC Voltage Range
Up to 240 Vac RMS

Power Factor at Full Charge Rate
> 98%

GENERAL SPECS

Operating Temperature Range
4 to 140 oF (-20 to 60 oC), with output derated
above 104 oF (40 degC)

Storage Temperature Range
-40 to 158 oF (-40 to 70 oC)

Operating Humidity Range
5 to 95% RH, non-condensing

Transfer Relay AC Current Rating
30 A surge, 24 A continous

DC Input/Output Nominal Voltage (inverting/
Charging)
12.0 Vdc

L x W x H (without flanges)
15.4 in(390 mm) x 10.8 in(275 mm) x 4.9 in(125 mm)

L x W x H (with flanges)
16.0 in(406 mm) x 12.0 in(305 mm) x 4.9 in(125 mm)

What's in the Box:

• Freedom XC PRO 2000
• one set of plastic bushings for large DC cables
• one pre-installed DC ground enclosure lug
• two AC knockout hole plugs

Powerful and Efficient Inverter Charger for Marine Applications

The Xantrex Freedom XC PRO 2000 is a powerful 2000W marine inverter charger designed to convert 12vDC power from your boat’s battery bank into reliable 120vAC power. This inverter charger offers exceptional efficiency with pure sine wave output, making it perfect for sensitive electronic devices onboard. It ensures consistent performance whether you are docked or cruising, providing a clean, stable power source for all your marine electrical needs. The seamless integration of inverter and charger capabilities means you can both power your AC devices and recharge your batteries efficiently while connected to shore power.

Advanced Features Enhancing User Experience and Safety

This model comes equipped with multiple advanced features such as automatic transfer switching that seamlessly changes power sources from shore power to inverter supply without interruption. It includes sophisticated charging profiles to optimize battery health by regulating voltage and current during charging. Safety is a top priority; the unit includes protections against overload, short circuit, high temperature, and low battery voltage. Its lightweight, compact, and impact-resistant design makes installation easier, ensuring rugged use in harsh marine environments.

Versatile Compatibility and Easy Installation

The Xantrex Freedom XC PRO 2000 is compatible with various battery types including AGM, Gel, and Flooded lead-acid batteries, making it a versatile choice for most marine setups. It supports a wide input voltage range and offers configurable settings via a user-friendly LCD display and keypad. Installation is straightforward, aided by clear instructions and mounting options within confined marine spaces. This inverter charger balances performance and reliability, making it an essential power management component for marine enthusiasts who demand uninterrupted power onboard.
